HYDROPOWER VALVES, FUSES, MANIFOLDS
Supplier Information
Name:
Novatek
Contact:
Sales or JulianWills
Phone:
011 210 0700
Email:
sales@novatek.co.za
Website:
http://www.novatek.co.za
Address:
6 Kindon Rd, undefined, undefined, Gauteng, 2091
The Novatek hydropower manifold is used in the working area to connect multiple tools to the incoming water supply via isolating fuses. It may also be used at a pump outlet to connect the delivery hose and provide connections for tools or test points. The Novatek hydropower fuse is both an isolating valve and a hydraulic safety fuse in one assembly. The function of the safety fuse is to rapidly reduce flow in the event of a downstream hose failure. • Independent isolating and fusing valves. No 1 and 2 are combined in a single unit. • No 3 fuse is combined with a separate ball valve to minimize flow losses. • Tolerant of dirt ingress. • Operation over a wide pressure range. • Simple operation; easy to troubleshoot.
| Equipment Type |
|
|---|---|
| OEM |
Novatek |
| TRL |
TRL9 |
| Mining Type |
Valves |
| Mine Development |
Stoping, Mine development |
| Mining Activity |
Drilling, Blasting, Cleaning, Roofbolting, Support |
| Mining Method |
Conventional, Hybrid |
| Mineral |
Gold, Platinum, Chrome, Hardrock, Coal |
| Energy source |
|
| Logistics & materials handling |
|
| ITComms |
|
| reefType |
|
